Page #84 background image
3.12.3 16-3* Drive Status
16-30 DC Link Voltage
Range: Function:
0 V* [0 - 65535 V] Shows the actual DC-link voltage.
16-34 Heatsink Temp.
Range: Function:
0 °C* [-128 - 127 °C] View the heat sink temperature of the
frequency converter.
16-35 Inverter Thermal
Range: Function:
0 %* [0 - 255 %] View the percentage of thermal load on the
frequency converter. At 100%, a trip occurs.
16-36 Inv. Nom. Current
Range: Function:
0 A* [0 - 655.35 A] View the inverter nominal current. The data
is used for motor overload protection and
so on.
16-37 Inv. Max. Current
Range: Function:
0 A* [0 - 655.35 A] View the inverter maximum current. The
data is used for calculation of frequency
converter protection and so on.
16-38 SL Controller State
Range: Function:
0* [0 - 20 ] View the actual state of the smart logic controller
(SLC).
3.12.4 16-5* Ref. & Feedb.
16-50 External Reference
Range: Function:
0 %* [-200 - 200 %] View the total reference, the sum of
digital, analog, preset, bus, and freeze
references.
16-52 Feedback[Unit]
Range: Function:
0
ProcessCtrlUnit*
[-4999 - 4999
ProcessCtrlUnit]
View the feedback resulting
from the selection of scaling
in parameter 3-02 Minimum
Reference and
parameter 3-03 Maximum
Reference.
16-54 Feedback 1 [Unit]
Range: Function:
0
ProcessCtrlUnit*
[-999999.999 -
999999.999
ProcessCtrlUnit]
View the feedback 1 value
resulting from the selection
of scaling in
parameter 3-02 Minimum
Reference and
parameter 3-03 Maximum
Reference.
16-55 Feedback 2 [Unit]
Range: Function:
0
ProcessCtrlUnit*
[-999999.999 -
999999.999
ProcessCtrlUnit]
View the feedback 2 value
resulting from the selection
of scaling in
parameter 3-02 Minimum
Reference and
parameter 3-03 Maximum
Reference.
3.12.5 16-6* Inputs and Outputs
16-60 Digital Input
Range: Function:
0* [0 -
4095 ]
View actual state of the digital inputs 18, 19, 27,
and 29.
Bit 0 Unused
Bit 1 Unused
Bit 2 Digital input terminal 29
Bit 3 Digital input terminal 27
Bit 4 Digital input terminal 19
Bit 5 Digital input terminal 18
Bit 6–15 Unused
Table 3.8 Bits Denition
16-61 Terminal 53 Setting
Option: Function:
View the setting of input terminal 53.
Current = 0
Voltage = 1
[0] * Current mode
[1] Voltage mode
16-62 Analog input 53
Range: Function:
1* [0 - 20 ] View the actual value at input 53.
Parameters
VLT
®
HVAC Basic Drive FC 101
82 Danfoss A/S © 04/2018 All rights reserved. MG18B502
