Option Function
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
Table 15: 36-7 - Low Flow
Option Function
Selects the soft starter's response if the flow drops below the low flow trip level (set in parameter 31-2 Low
Flow Trip Level).
* Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
Table 16: 36-8 - Flow Switch
Option Function
Selects the soft starter's response if the flow sensor closes (switch type sensors only).
* Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
6.4 Pressure Protection
Pressure protection uses terminals B23, B24 or C33, C34, C43, C44 on the smart card.
• B23, B24: Use an analog 4–20 mA sensor.
• C33, C34 (low-pressure protection): Use a normally open digital switch sensor.
• C43, C44 (high-pressure protection): Use a normally open digital switch sensor.
Pressure protection is active when the soft starter is in the start, run, or stop mode.
The smart card trips the soft starter when the pressure level passes through the programmed trip level. If the pressure is still outside
the expected operating range when the trip is reset (including auto-reset), the soft starter does not trip again.
Configuration
Installation Guide | Pumping Smart Card
AN279052730268en-000102 / 175R1183
16 | Danfoss A/S © 2018.10
