Table 47: 34-4 - Depth Response Delay
Range Function
* 0.5 s 00:00:100–30:00:000
mm:ss:ms
Sets a delay between the depth passing the depth protection trip level and the soft starter trip-
ping.
6.6.1.5 Parameter Group 36-** Pump Trip Action
Table 48: 36-3 - Depth Sensor
Option Function
Selects the soft starter's response if it detects a fault with the depth sensor.
* Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
Table 49: 36-9 - Well Depth
Option Function
Selects the soft starter's response if the depth drops below the depth trip level (parameter 34-1 Depth Trip
Level) or the depth switch sensor closes.
* Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
6.7 Thermal Protection
Thermal protection uses terminals R1, R2, R3 on the smart card.
Thermal protection is active only when the soft starter is in run mode.
Configuration
Installation Guide | Pumping Smart Card
AN279052730268en-000102 / 175R1183 | 27
