Table 23: 32-3 - High Pressure Response Delay
Range Function
* 0.5 s 00:00:100–30:00:000
mm:ss:ms
Sets a delay between the pressure passing the high-pressure trip level and the soft starter trip-
ping.
Table 24: 32-4 - Low Pressure Trip Level
Range Function
* 5 0–5000 Sets the trip point for low-pressure protection.
Table 25: 32-5 - Low Pressure Start Delay
Range Function
* 0.5 s 00:00:100–
30:00:000
mm:ss:ms
Sets a delay before a low-pressure protection trip can occur. The delay is counted from the time a
start signal is received. The pressure is ignored until the start delay has elapsed.
Table 26: 32-6 - Low Pressure Response Delay
Range Function
* 0.5 s 00:00:100–30:00:000
mm:ss:ms
Sets a delay between the pressure passing the low-pressure trip level and the soft starter trip-
ping.
6.4.1.5 Parameter Group 36-** Pump Trip Action
Table 27: 36-1 - Pressure Sensor
Option Function
Selects the soft starter's response if it detects a fault with the pressure sensor.
* Soft and Trip Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
Table 28: 36-4 - High Pressure
Option Function
Selects the soft starter's response if the pressure exceeds the high-pressure trip level (parameter 32-1 High
Pressure Trip Level) or the high-pressure switch sensor closes.
* Soft Trip and Log
Soft Trip and Reset
Trip Starter
Configuration
Installation Guide | Pumping Smart Card
AN279052730268en-000102 / 175R1183 | 19
Danfoss A/S © 2018.10
