Table 124: 6-9 - Overpower
Option
Function
Selects the soft starter's response to the protection event.
Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
*
Log Only
Shunt+Trip Relay
Table 125: 6-10 - Excess Start Time
Option
Function
Selects the soft starter's response to the protection event.
*
Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
Trip+Shunt Relay
Table 126: 6-11 - Input A Trip
Option
Function
Selects the soft starter's response to the protection event.
*
Soft Trip and Log
Soft Trip and Reset
Trip Starter
Trip and Reset
Warn and Log
Log Only
Trip+Shunt Relay
Table 127: 6-12 - Input B Trip
Option
Function
Selects the soft starter's response to the protection event.
AQ262141844215en-000401 / 175R1174 | 97
Danfoss A/S © 2020.12
Programmable Parameters
VLT® Soft Starter MCD 600
Operating Guide
100
102
