10 Programmable Parameters
10.1 Main Menu
Use the Main Menu to view and change programmable parameters that control how the soft starter operates.
To open the Main Menu, press [Menu/Store], scroll to Main Menu, and press [Menu/Store] again.
N O T I C E
Parameters for smart card functions are only visible in the parameter list if the smart card is installed.
10.2 Changing Parameter Values
Procedure
Scroll to the parameter in the Main Menu.
Press [Menu/Store] to enter edit mode.
Press [▵] or [▿] to change parameter settings.
Pressing [▵] or [▿] once increases or decreases the value by 1 unit. If the key is held for longer than 5 s, the value increases
or decreases at a faster rate.
Press [Store] to save changes. The setting shown on the display is saved and the LCP returns to the parameter list.
Press [Back] to cancel changes. The LCP asks for confirmation, then returns to the parameter list without saving the
changes.
10.3 Adjustment Lock
Use parameter 10-7 Adjustment Lock to prevent users from changing parameter settings.
If a user attempts to change a parameter value when the adjustment lock is active, the following error is shown: Access Denied. Adj
Lock is On.
10.4 Parameter List
Table 29: Parameter List
Parameter group number
Parameter group name
Default setting
1
Motor Details
1-1
Command Source
Digital Input
1-2
Motor Full Load Current
Model dependent
1-3
Motor kW
0 kW
1-4
Locked Rotor Time
00:10 (mm:ss)
1-5
Locked Rotor Current
600%
1-6
Motor Service Factor
105%
1-7
Reserved
–
2
Motor Start/Stop
2-1
Start Mode
Constant Current
2-2
Start Ramp Time
00:10 (mm:ss)
2-3
Initial Current
200%
2-4
Current Limit
350%
2-5
Adaptive Start Profile
Constant Acceleration
AQ262141844215en-000401 / 175R117474 | Danfoss A/S © 2020.12
Programmable Parameters
VLT® Soft Starter MCD 600
Operating Guide
