Parameter group number
Parameter group name
Default setting
36-2
Flow Sensor
Soft Trip and Log
36-3
Depth Sensor
Soft Trip and Log
36-4
High Pressure
Soft Trip and Log
36-5
Low Pressure
Soft Trip and Log
36-6
High Flow
Soft Trip and Log
36-7
Low Flow
Soft Trip and Log
36-8
Flow Switch
Soft Trip and Log
36-9
Well Depth
Soft Trip and Log
36-10
RTD/PT100 B
Soft Trip and Log
40
Ground Fault
40-1
Ground Fault Level
0 A
40-2
Ground Fault Delay
00:01 (mm:ss)
40-3
Ground Fault Trip Active
Operating only
40-4
Ground Fault Action
Soft Trip and Log
40-5
Ground Fault CT Ratio
1000:1
10.5 Parameter Group 1-** Motor Details
Table 30: 1-1 - Command Source
Option
Function
Selects the command source for controlling the soft starter.
*
Digital input
The soft starter accepts start and stop commands from the digital inputs.
Network
The soft starter accepts start and stop commands from the communication expansion card.
Remote LCP
The soft starter accepts start and stop commands from the remote LCP.
Clock
The soft starter accepts starts and stops as scheduled in parameters 4-1 to 4-24.
Smart card
The soft starter accepts start and stop commands from the smart card.
Smart card +
clock
The soft starter accepts start commands from the smart card if they are within the operating schedule set
in parameters 4-1 to 4-24. A stop command from the smart card is accepted regardless of the schedule.
Timer
After a start signal is received, the soft starter starts and stops the motor according to the timers set in
parameter 4-2 Run Time and parameter 4-3 Stopped Time.
Table 31: 1-2 Motor Full Load Current
Range
Function
Model dependent
Matches the soft starter to the FLC of the motor. Set to the FLC rating shown on the motor nameplate.
AQ262141844215en-000401 / 175R117482 | Danfoss A/S © 2020.12
Programmable Parameters
VLT® Soft Starter MCD 600
Operating Guide
