Danfoss VLT Micro Drive FC 51 Series Programming Guide

4.1.3. 0-32 Custom Readout Max Scale
0-32 Custom Readout Max Scale
Range: Function:
100.0 * [0.00 – 9999.00]
It is possible to create a customized readout related to the output frequency of the unit. The value entered in
par. 0-32 will be shown at the frequency programmed in par. 4-14 Motor Speed High Limit. The readout can be
shown in the LCP display when in Status Mode or it can be read in par. 16-09
4.1.4. 0-4* LCP Keypad
The frequency converter can operate in the following three modes: Hand , Off and Auto .
Hand: The frequency converter is locally operated and does not allow any remote control. By activating Hand a start signal is given.
OFF: The frequency converter stops with a normal stop ramp. When Off is chosen the frequency converter can only be started by pressing either Hand
or Auto on the LCP.
Auto: In Auto-mode the frequency converter can be remote controlled (bus/digital).
0-40 [Hand on] Key on LCP
Option: Function:
[0] Disabled Hand-on key has no function.
[1 ]
*
Enabled Hand-on key is functional.
0-41 [Off/Reset] Key on LCP
Option: Function:
[0] Disable Off/Reset Off/reset key has no function.
[1 ]
*
Enable Off/Reset Stop signal and reset of any faults.
[2] Enable Reset Only Reset only. Stop (Off) function is disabled.
0-42 [Auto on] Key on LCP
Option: Function:
[0] Disabled Auto-on key has no function.
[1 ]
*
Enabled Auto-on key is functional.
4.1.5. 0-5* Copy/Save
0-50 LCP Copy
Option: Function:
The detachable LCP of the frequency converter can be used for storing setups, and thus for transferring data
when moving parameter settings from one frequency converter to another.
NB!
LCP Copy can only be activated from the LCP and ONLY when the motor is coasted.
[1] All to LCP Copy all setups from the frequency converter into the LCP.
[2] All from LCP Copy all setups from LCP to frequency converter.
[3] Size indep. from LCP Copy non motor size dependent data from LCP to frequency converter
0-51 Set-up Copy
Option: Function:
Use this function to copy a set-up content into the Edit Set-up .
In order to be able to make a set-up copy ensure that
• the motor is coasted
• par. 0-10,
Active Set-up , is set to either Set-up 1 [1] or Set-up 2 [2]
VLT
p
Micro Drive FC 51 4. Parameter Descriptions
MG.02.C4.02 - VLT
p
is a registered Danfoss trademark 13
4
