Danfoss VLT Pocket Guide

VLT
®
Soft Starter Pocket Guide 11
Normal Heavy Severe
MCD3007 17 16 14
MCD3015 30 28 24
MCD3018 36 33 29
MCD3022 45 40 35
MCD3030 57 54 47
MCD3037 76 72 62
MCD3045 83 78 68
M CD30 55 111 10 4 9 0
MCD3075 117 113 99
MCD3090 172 164 143
MCD3110 205 194 169
MCD3132 211 202 178
MCD3185 326 (489) 261 (392) 222 (333)
MCD3220 383 (575) 308 (462) 262 (394)
MCD3300 507 (761) 393 (590) 329 (493)
MCD3315 600 (900) 456 (684) 377 (566)
MCD3400 775 (1162) 567 (850) 458 (687)
MCD3500 822 (1233) 602 (904) 472 (709)
MCD3600 998 (1497) 797 (1195) 713 (1070)
MCD3700 1248 (1873) 990 (1485) 865 (1297)
MCD3800 1433 (2149) 1128 (1693) 961 (1442)
Brackets denote ratings for inside delta connection.

Danfoss VLT Specifications

General

Frequency	50/60 Hz
Enclosure	IP20, IP21, IP55, IP66
Series	VLT
Control Technique	Flux Vector Control
Output Voltage	0-Vinput
Control Method	Fieldbus
Communication Interface	PROFIBUS, CANopen
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Cooling Method	Liquid Cooled
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% non-condensing
Altitude	Up to 1000m (3280ft) without derating, up to 4000m (13120ft) with derating
Operating Temperature	-10°C to +50°C (14°F to 122°F)
