DataCard CD800 User Manual

XPS Card Printer Driver User’s Guide 13
6. Use the printer LCD screen menu system to retrieve the printer’s IP address. Press the down
arrow until the IP address displays and write down the address.
7. Enter the IP address.
The Installing Network Driver window displays on your PC.
The Card Printer Driver supports both IPv4 and IPv6 addresses for network-
connected printers. Refer to your printer’s User’s Guide for complete information
about obtaining an IPv6 address.

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
