Datacard CE870 User Reference Guide Load Cards
13
12
Clean the Multi-Hopper Rollers
1. Unlock and open the input hopper cover.
2. Load cleaning cards into each hopper.
3. Close the input hopper and lock the printer.
4. Follow the steps on the LCD panel (refer to the following illustraon).
5. Press ENTER to start the cleaning process.
Load Cards
• Fan the cards to separate the edges.
• Insert ISO magnec stripe cards with the stripe facing down and to the right.
• Insert smart cards with the chip facing up and toward the back of the hopper.
Note: A diagram inside the hoppers shows the correct orientaon for each type of
card.
Single Hopper Printer
1. Unlock the printer and open the input hopper.
2. Load cards into the input hopper.
3. Close the hopper and lock the printer.
Multi-Hopper Printer
1. Unlock the printer and open the mul-hopper door.
2. Load cards into each hopper (H1 through H6). Each hopper holds up to 100
cards.
3. Close the mul-hopper door and lock the printer.

DataCard CE870 Specifications

General

Brand	DataCard
Model	CE870
Category	Printer
Language	English
