DataCard SD260 User Guide

XPS Card Printer Driver User’s Guide 83
Use a User-Defined Topcoat Bitmap
User-defined bitmaps allow you to apply topcoat to a card in custom patterns or shapes when the
predefined blocking areas and escapes are not sufficient. The bitmap files are installed as part of
the Card Printer Driver Installation in the C:\CardPrinter folder. If you previously used an older-
generation desktop printer, the bitmap files may already be on your PC.
The topcoat bitmap used depends on the card side and orientation you specify.
Side Orientation Bitmap File
1Portrait CRDPortTopcoatFront.bmp
2 Portrait CRDPortTopcoatBack.bmp
1 Landscape CRDLandTopcoatFront.bmp
2 Landscape CRDLandTopcoatBack.bmp
If the bitmap files are already installed on your computer, a new driver installation or
update does not overwrite the existing files.

DataCard SD260 Specifications

General

Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Color	Yes
Print speed (color)	200 card/h
Product color	Blue, Grey

Weight and Dimensions

Depth	391 mm
Width	175 mm
Height	224 mm
