Datakom DKG-509 User Manual

DKG-509 User Manual V-29 (23.08.2013)
- 29 -
Below is a basic list of fault conditions (x denotes any FMI)
SPN
FMI
DESCRIPTION
94
x
Fuel filter restriction
Fuel pressure sensor fail
98
x
Low oil level
High oil level
Oil level sensor fail
100
x
Low oil pressure
Oil pressure sensor fail
102
x
High boost pressure
Turbo outlet pressure sensor fail
105
x
Intake manifold temp high
Intake manifold temp sensor fail
107
x
Air filter restriction
Air filter sensor fail
108
x
Athmospheric pressure sensor fail
110
x
High coolant temperature
Coolant temperature sensor fail
111
x
Low coolant level
Coolant level sensor fail
164
x
High injector activation pressure
Injector activation pressure sensor fail
168
x
Battery voltage failure
172
x
High inlet air temperature
High inlet manifold air temperature
Inlet manifold air temperature sensor fail
174
x
High fuel temperature
Fuel temperature sensor fail
175
x
High oil temperature
Oil temperature sensor fail
190
x
Overspeed
Speed sensor loss of signal
Speed sensor mechanical failure
228
x
Timing calibration required
234
x
Incorrect ecm software
620
x
ECU internal +5V fail
629
x
ECU hardware fail
651
x
Injector cylinder #1 fault
652
x
Injector cylinder #2 fault
653
x
Injector cylinder #3 fault
654
x
Injector cylinder #4 fault
655
x
Injector cylinder #5 fault
656
x
Injector cylinder #6 fault
657
x
Injector cylinder #7 fault
657
x
Injector cylinder #8 fault
678
x
ECU internal power supply fail
723
x
Secondary engine speed sensor fail
1108
x
Critical override enabled
1111
x
Check configuration parameters
2000
x
ECU failure
