Datalogic DS2400N Quick Reference Guide

DS2400N QUICK GUIDE
15
READING PERFORMANCE
Version Reading Distance Max Code Resolution
mm (mils)
Speed
scans/s
0XX0 75 mm (3 in) - 340 mm (13.4 in) on 0.35 mm (14 mils) codes 0.20 (8) 600 to 1000
1XX0 100 mm (3.9 in) - 440 mm (17.3 in) on 0.50 mm (20 mils) codes 0.25 (10) 600 to 1000
2XX0 190 mm (7.5 in) - 600 mm (23.6 in) on 0.50 mm (20 mils) codes 0.35 (14) 600 to 1000
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power Supply 10 to 30 Vdc
Consumption 0.5 to 0.17 A; 5 W
Main Serial Interfaces
Baud Rate
Programmable:
RS232, RS485 FD and HD
1200 to 115200
Auxiliary Interface
Baud Rate
RS232
1200 to 115200
ID-NET™ Interface
Baud Rate
RS485 Half Duplex
Up to 1 Mbaud
Inputs
Input 1 (External Trigger), Input 2
Voltage
Current Consumption
Minimum Pulse Duration
Optocoupled, polarity insensitive
10 to 30 Vdc
12 mA max.
5 ms
Outputs
Output 1, Output 2
V
CE
Collector Current
V
CE Saturation
Power Dissipation
Optocoupled
30 Vdc max.
40 mA continuous max.; 130 mA pulsed max.
1V max. at 10 mA
80 mW max. at 45 °C (ambient temperature)
READING FEATURES
Scan Rate (software programmable) 600 to 1000 scans/sec
Aperture Angle 50°
Maximum Reading Distance
Maximum Resolution
See reading diagrams
ENVIRONMENTAL FEATURES
Operating Temperature c 0° to +45 °C (+32° to +113 °F)
Storage Temperature -20° to +70 °C (-4° to +158 °F)
Humidity max. 90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance
EN 60068-2-29
30 g; 6 ms;
5000 shocks on each axis
Shock Resistance
EN 60068-2-27
30 g; 11 ms;
3 shocks on each axis
Protection Class
EN 60529
IP65
PHYSICAL FEATURES
Dimensions
68 x 84 x 34 mm (2.68 x 3.31 x 1.34 in)
Weight 330 g (11.6 oz)
USER INTERFACE
LED Indicators
Ready, Good, Trigger, Com, Status, Power On
Multi-function Key X-PRESS™ button
c If the reader is used in high temperature environments (over 40 °C), use of the Beam Shutter is advised (see the Genius™
configuration program) and/or a thermally conductive support (such as the metal bracket provided).

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
