General| Type | - |
|---|---|
| Sensor type | Laser |
| Read rate (max) | 1000 reads/s |
| Linear (1D) barcodes supported | Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C. |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Standard interfaces | RS-232, RS-485 |
| Connectivity technology | Wired |
| Input voltage | 10 - 30 V |
| Power source type | DC |
| Power consumption (typical) | 5 W |
| Certification | IEC |
| Product color | Blue, Yellow |
| Housing material | Aluminum |
| International Protection (IP) code | IP65 |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
Weight and Dimensions| Depth | 34 mm |
|---|---|
| Width | 84 mm |
| Height | 68 mm |
| Weight | 330 g |
