INSTALLATION
2
18/6/14 +
19/10/15
-
USER INTERFACEDS4600
A
Signal
+ 5V
VS
9
25
GND
Ground
V
Figure 15 - Input NPN Command Using DS4600A Power
18/6/14
+
19/10/15
-
+ 5V
DS4600
A
USER INTERFACE
V
Signal
Ground
30 Vdc max.
Vext
Figure 16 - Input PNP Command Using External Power
18/6/14 +
19/10/15
-
USER INTERFACE
DS4600
A
VS
9
25
GND
V
Signal
+ 5V
Figure 17 - Input PNP Command Using DS4600A Power
15
