DS4600A
6
6 TECHNICAL FEATURES
ELECTRICAL FEATURES
DS4600A-XXX0 DS4600A0-2XX5
Power
Supply Voltage 10 to 30 Vdc 24 Vdc
Power Consumption max. 6 W 12W
Serial Interfaces
Main RS232, RS485 full-duplex, RS485 half-duplex
(20 mA C.L. only with C-Box 100 and INT-30 accessory )
Auxiliary RS232
Baudrates
1200 to 115200
Inputs External Trigger, IN1, IN2
(optocoupled NPN or PNP)
Voltage max. 30 Vdc
Input Current max. 25 mA
Outputs User-defined OUT1 and OUT2
(optocoupled open emitter, open collector)
V
CE
max. 40 Vdc
Collector Current max. 40 mA continuous; 130 mA pulsed
V
CE
saturation 1V at 10 mA max.
Power Dissipation max.
90 mW at 40
°C (Ambient temp.)
OPTICAL FEATURES
Light Source Semiconductor laser diode
Wavelength (Note 1) 630 ~ 680 nm
Safety Class Class 2 – EN60825-1; CDRH
READING FEATURES (Note 2)
200X / 300X 210X / 310X 220X / 320X
Aperture Angle 66° 70° 60°
Maximum Resolution 0.25 mm
(10 mils)
0.50 mm
(20 mils)
0.20 mm
(8 mils)
Max. Reading Distance See reading diagrams
Scan Rate 800 scans/sec
USER INTERFACE
LED Indicators Ready, Good Read,
External Trigger , Data Transmission
44
