The reading characteristics for the raster versions are given in the table below. The
distance between the top and bottom scan lines is given at different reading
distances measured from the laser beam output window.
Reading Distance
Version
150 mm
(5.9 in)
500 mm
(20 in)
800 mm
(31.5 in)
2X1X (R1)
7.5 mm
(0.30 in)
24 mm
(0.94 in)
37 mm
(1.46 in)
2X2X (R2)
16 mm
(0.62 in)
45 mm
(1.77 in)
71 mm
(2.80 in)
Refer to the diagrams given in paragraph 3.4 for further details on the reading
features. These diagrams are taken on various resolution sample codes at a 25
°C
ambient temperature, depending on the conditions in the notes under each diagram.
If standard devices do not satisfy specific requirements, contact your nearest
Datalogic distributor, supplying code samples, to obtain complete information on the
reading possibilities.
