Datalogic DS4600A User Manual

READING FEATURES
3
DS4600A-32XX (Short Range)
4
2
0
-2
10
8
6
-4
-6
-8
-10
(in)
02 64 2012
(in)
810 141618
0
40
80 120
160
200 240
280 320
360
400
440
480
520
(mm)
240
200
160
120
80
40
0
-40
-80
-120
-160
-200
-240
(mm)
0.20 mm
(8 mils)
0.25 mm
(10 mils)
≥
0.30 mm
(12 mils)
NOTE: (0,0) is the center of the laser beam output window
CONDITIONS
Test Codes used = Interleaved 2/5 and Code 39
PCS = 0.90
"Pitch" angle = 0
°
"Skew" angle = 15
°
"Tilt" angle = 0
°
*SW Resolution = High
* Parameter selectable in WinHost
39
