Datalogic Gryphon 4200 Series Quick Reference Guide

Setting Up the Reader
QUICK REFERENCE GUIDE 3
SETTING UP THE READER
Follow the steps below to connect and get your reader up
and communicating with its host.
1. Connect the Cable to the reader and the Host as
shown below.
2. Configure the Interface (see page 7).
3. Program the Reader starting on page 16 (optional,
as needed).
Connecting to the Host Interface
USB
WEDGE
RS-232

Datalogic Gryphon 4200 Series Specifications

General

Brand	Datalogic
Model	Gryphon 4200 Series
Category	Barcode Reader
Language	English
