Using the Gryphon™ I GD4200
QUICK REFERENCE GUIDE
5
Relative Size and Location of Aiming Pattern
Linear Bar
A red beam illuminates the label. The field of view indi-
cated by the aiming system will be smaller when the
reader is closer to the bar code and larger when it is far-
ther from the code. Symbologies with smaller bars or ele-
ments (mil size) should be read closer to the unit.
Symbologies with larger bars or elements (mil size) should
be read farther from the unit. If the aiming system is cen-
tered and the entire bar code is within the aiming field,
you will get a good read. Successful reading is signaled by
an audible tone plus a good-read green spot LED indicator.
Refer to the Gryphon I GD4200 Product Reference Guide
(PRG) for more information about this feature and other
programmable settings.
