Connecting the Base Station
Quick Reference Guide 7
3. The stand can now be repositioned in either horizontal
or standing position.
Connecting the Base Station
Figure 1 shows how to connect the Base Station to a terminal, PC
or other host device. Turn off the host before connection and con-
sult the manual for that equipment (if necessary) before proceed-
ing. Connect the interface cable before applying power to the Base
Station.
Base Station Connection and Routing:
Fully insert the Power Ca-
ble and Interface (I/F) Cable connectors into their respective ports
in the underside of the Base Station (see Figure 1). Then connect
to an AC Adapter, and plug the AC power cord into the (wall)
outlet.
NOTE
Gryphon BT can also be Powered by the Terminal. The
external power supply is recommended but not necessary.
When powered by the Terminal, the battery charger is
automatically set as Slow charge.
