Charging the Batteries
Quick Reference Guide 11
Table 1. Radio Base LEDs
The button can be used to force device connection via the Data-
logic Aladdin Software tool, and for paging the scanner when it is
activated. Refer to the Gryphon I Product Reference Guide
(PRG) for a more detailed explanation.
Charging the Batteries
To charge the battery, simply insert the Gryphon into the base.
The LEDs on the base (shown in
Table 1 above) will indicate the
status of the battery.
LED STATUS
Power on / Data
Yellow On = Base is powered
Yellow Blinking = Base receives data and
commands from the Host or the Reader.
Charging Red On = the Battery is charging.
Charge completed Green On = the Battery is completely charged.
Charging +
Charge completed
Red and Green Blinking together = the Reader
is not correctly placed onto the Base.
NOTE
Before using the Battery, read “Battery Safety” in the
following section. Datalogic recommends annual
replacement of rechargeable battery packs to ensure
maximum performance.
