Connecting the Base Station
10 Gryphon™ I GBT4100
Disconnecting the Cable:
To detach the cable, insert a paper clip
or similar object into the hole on the base, as shown in Figure 5.
Figure 5. Disconnecting the Cable
Using the BC40xx™ Radio Base
Radio Base LEDs
LEDs on the Gryphon I Base provide information about the Bases
well as battery charging status, as shown in Figure 6.
Figure 6. Gryphon I Base LEDs
The following table describes the significance of each LED.
NOTE
Gryphon BT can also be Powered by the Terminal. The exter-
nal power supply is recommended but not necessary. When
powered by the Terminal, the battery charger is automati-
cally set as Slow charge.
