Technical Specifications
QUICK REFERENCE GUIDE 25
Frame Rate 60 full-frame/s
Reading Angles Pitch: +/- 60°; Roll (Tilt): +/- 180°; Skew (Yaw): +/- 60°
Reading Indicators
Beeper (Adjustable Tone and volume);
Datalogic ‘Green Spot’
Good Read Feedback;
Top-Front Good Read LED with Adjustable brightness
Resolution (Maxi-
mum)
1D Linear: 0.076 mm / 3 mils
Data Matrix: 0.13 mm / 5 mils
PDF417: 0.13 mm / 5 mils
INTERFACES
INTERFACES
GFS4520: USB (micro-USB connector)
GFS4550: RS232 (2m straight cable DB9 connector)
GFS4590: USB / RS232 (10cm multi-interface connec-
tor)
GFE4590: USB / RS232 (12 pin connector)
Digital I/O
GFS4550 / GFE4590: One SW Programmable digital
input + one SW programmable digital output
DOF - DEPTH OF FIELD
A
Resolution [mils]
Code 39
5 mil: 4 to 30.0 cm / 0.16 to 11.8 in
10 mil: 1.7 to 53.5 cm / 0.6 to 21.0 in
Data Matrix
10 mil: 3.5 to 23.5 cm / 1.3 to 9.6 in
15 mil: 3.0 to 35.0 cm / 1.2 to 13.7 in
EAN/UPC 13 mil: 4.0 to 82.0 cm / 1.6 to 32.3 in
PDF417 10 mil: 1.5 to 35.0 cm / 5.9 to 13.7 in
QR Code 10 mil: 3.5 to 22.0 cm / 1.4 to 8.7 in
a. Minimum distance determined by symbol length and scan angle. Printing reso-
lution, contrast, and ambient light dependent.
DECODE CAPABILITY
1D / Linear Codes
Auto discriminates all standard 1D codes including GS1
DataBar™ linear codes.
2D Codes
Aztec Code; China Han Xin Code; Data Matrix; Maxi-
Code; Micro QR Code; QR Code; Dot Code; Dot Matrix
Postal Codes
Australian Post; British Post; China Post; IMB; Japa-
nese Post; KIX Post; Planet Code; Postnet; Royal Mail
Code (RM4SCC)
Stacked Codes
EAN/JAN Composites; GS1 DataBar Composites; GS1
DataBar Expanded Stacked; GS1 DataBar Stacked; GS1
DataBar Stacked Omnidirectional; MacroPDF; Micro-
PDF417; PDF417; UPC A/E Composites
Digital Watermarking Digimarc Barcodes
REGULATORY
See Regulatory Addendum included with your product.
