SETUP
10
GRYPHON™ I GD/GBT/GM4200
POSITIONING THE BASE STATION
The base station/charger may be set up in desk application to hold the reader in two dif-
ferent positions, either a horizontal or vertical position, in order to provide the most
c
omfortable use depending on the needs.
Base Station Positions and Related Clips to be Used
Figure 5 - Horizontal Position
This position is preferred, unless a different specific positioning is required, for its
utmost ease of insertion as well as the minimum effort and attention required by the
customer when docking the scanner.
