Datalogic Gryphon I GPS4400 Quick Reference Guide

Setting Up the Reader
12 Gryphon™ GPS4400
Attaching/Detaching the Stand
The reader can be removed or attached to the stand simply by snap-
ping on or off. To attach, align the holes on the bottom of the scanner
with the posts on the stand and push down to snap in place. To
remove, just pull straight up to detach the reader from the base.
For specific size information, see GPS4400 Dimensions on page 29.
If desired, the stand can be mounted to a stationary surface using
two screws.
Attaching/Detach-
ing the Stand
Screw holes
Stand bottom

Datalogic Gryphon I GPS4400 Specifications

General

Type	Fixed bar code reader
Sensor type	Laser
Scanner type	2D
Tilt reading angle	-180 - 180 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	5 V
USB version	2.0
Standard interfaces	USB, RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Buzzer	Yes
Product color	White
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	73 mm
Width	121 mm
Height	107 mm
Weight	295 g
