Datalogic Gryphon I GPS4400 Quick Reference Guide

Table of Contents
Reading a Bar Code ........................................................................................... 8
Setting Up the Reader ...................................................................................... 9
USB Interface ............................................................................... 10
Attaching/Detaching the Stand .......................................................... 12
Programming .................................................................................................. 13
Using Programming Bar Codes ........................................................... 13
Configure Other Settings ...................................................................... 13
Resetting Product Defaults .................................................................. 14
Aiming System ...................................................................................... 14
Good Read Green Spot Duration .......................................................... 15
Operating Modes ................................................................................... 16
Technical Features .......................................................................................... 18
Host Interface Connections ................................................................. 23
LED and Beeper Indications ........................................................................... 24
Indicators ......................................................................................................... 25
Error Codes ...................................................................................................... 28
GPS4400 Dimensions.................................................................. 29
Ergonomic Recommendations ...................................................................... 31
Regulatory Information .................................................................................. 32
Statement of Agency Compliance ....................................................... 32
FCC Class B Compliance Statement .................................................... 32
Canadian Notice .................................................................................... 33
Power Supply ......................................................................................... 33
Reader Labeling .............................................................................................. 34
Aiming System............................................................................. 34
WEEE Statement ............................................................................................ 40
Datalogic ADC Limited Factory Warranty ..................................................... 41
Services and Support ...................................................................................... 44
Products ....................................................................................... 44
Service & Support........................................................................ 44
Contact Us.................................................................................... 44

Datalogic Gryphon I GPS4400 Specifications

General

Type	Fixed bar code reader
Sensor type	Laser
Scanner type	2D
Tilt reading angle	-180 - 180 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	5 V
USB version	2.0
Standard interfaces	USB, RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Buzzer	Yes
Product color	White
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	73 mm
Width	121 mm
Height	107 mm
Weight	295 g
