Datalogic Gryphon I GPS4400 Quick Reference Guide

Technical Features
22 Gryphon™ GPS4400
Interfaces Supported
RS-232 types: STD, W-N & OPOS
USB types: COM, KBD & OEM
User Environment
Operating Temperature 0° to 50° C (32° to 122° F)
Storage Temperature -40° to 70° C (-40° to 158° F)
Humidity
Operating: 5% to 90% relative humidity, non condens-
ing
Drop specifications 5 drops from 4 feet (1.2 m) to concrete
Ambient Light immunity Up to 100,000 Lux
Contaminants IEC529-IP52
ESD Level 16 KV
Regulatory
LED Emission Class
(IEC-62471:2006-07) Exempt (No Risk)
IEC60825-1: 2007
Electrical Safety IEC/EN60950-1
EMI/EMC EN55022/EN55024
Laser Safety IEC Class 2
Wavelength: 650nm
Beam Divergence: ±8°
Pulse Duration: Continuous Wave
Max Power Output: 1mW Avg.

Datalogic Gryphon I GPS4400 Specifications

General

Type	Fixed bar code reader
Sensor type	Laser
Scanner type	2D
Tilt reading angle	-180 - 180 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	5 V
USB version	2.0
Standard interfaces	USB, RS-232
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Buzzer	Yes
Product color	White
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	73 mm
Width	121 mm
Height	107 mm
Weight	295 g
