Datalogic Heron D130 - Pen Reader Configuration Options; Restore Default Pen Settings; Pen Interface Mode Selection

USB KEYBOARD NATIONALITY (Continued)
USA
i'+]k
i'+]k
i'+]k
Japanese
i'+k
i'+k
i'+k
RS232 READER CONFIGURATION
Read the RESTORE DEFAULT
code, then read the interface
selection code for your application.
RESTORE DEFAULT
iPk
iPk
iPk
RS232
Standard
i$1k
i$1k
i$1k
POS Systems
Nixdorf Mode A
i$.k
i$.k
i$.k
Fujitsu
i$.ek
i$.ek
i$.ek
ICL Mode
i$.`k
i$.`k
i$.`k
PEN READER CONFIGURATION
Read the RESTORE DEFAULT
code, then read the PEN
interface selection code.
RESTORE DEFAULT
iPk
iPk
iPk
PEN
i$1#k
i$1#k
i$1#k
DEFAULT VALUES
USB DEFAULT SETTINGS
DATA FORMAT : code identifier disabled, no field adjustment,
code length not transmitted, character replacement disabled.
USB KEYBOARD : USA keyboard, inter-character and inter-
code delays disabled, control character emulation =
ctrl+shift+key;
USB COM : no handshaking, delay disabled, rx timeout 5 sec.,
ack/nack disabled, FIFO enabled, serial trigger lock disabled;
Default Headers and Terminators for each USB mode:
- USB-KBD: no header, terminator = ENTER
- USB-KBD-ALT-MODE: no header, terminator = CR
- USB-COM: no header, terminator = CR-LF
- USB-IBM-TABLE TOP: not applicable
- USB-IBM-HAND HELD: not applicable
RS232 Standard DEFAULT SETTINGS
9600 baud, no parity, 8 data bits, 1 stop bit, no handshaking,
delay disabled, rx timeout 5 sec., ack/nack disabled, FIFO
enabled, serial trigger lock disabled;
DATA FORMAT : code identifier disabled, no field adjustment,
code length not transmitted, no header, terminator = CR-LF,
character replacement disabled
RS232 Nixdorf DEFAULT SETTINGS
9600 baud, parity odd, 8 data bits, 1 stop bit, handshaking
hardware (RTS/CTS), delay disabled, rx timeout 9.9 sec.,
ack/nack disabled, FIFO enabled, serial trigger lock disabled;
