Datalogic Heron D130 User Manual

PATENTS
This product is licensed
under one or more of the following
U.S. patents:
4,282,425; 4,570,057; 4,766,300; 4,894,523; 5,021,642;
5,038,024; 5,081,343; 5,095,197; 5,144,119; 5,144,121;
5,182,441; 5,187,355; 5,187,356; 5,218,191; 5,233,172;
5,258,606 and /or 5,288,985
This product is covered
by one or more of the following patents
and patent applications:
US 5,917,176; US 5,992,740; US 6,010,073;
US pat. Appl. 99US-320.643; US pat. Appl. 99US-362.988;
US pat. Appl. 98US-126.606; EP pat. Appl. 00EP-830.127;
EP pat. Appl. 00EP-830.122; EP pat. Appl. 98EP-830.336;
EP pat. Appl. 98EP-830.611; EP pat. Appl. 97EP-200.317;
EP pat. Appl. 97EP-830.408; EP pat. Appl. 96EP-830.473;
EP pat. Appl. 96EP-830.660; EP pat. Appl. 96EP-830.439
FCC COMPLIANCE
This device complies with PART 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference which
may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
USB
With the USB cable, this accessory device is intended to be
supplied by a UL Listed Power Unit marked "Class 2", or an
LPS power source which supplies power directly to the reader.
IBM USB POS
With the USB cable, this accessory device is intended to be
connected to a UL Listed computer which supplies power
directly to the reader.
PEN
With the Pen Emulation cable, this accessory device is
intended to be supplied by a UL Listed Power Unit marked
"Class 2", or an LPS power source which supplies power
directly to the reader.
(if required)

Datalogic Heron D130 Specifications

General

Sensor type	CCD
Decoding standards	-2/5. -Code 39 (plus Code 32, Cip 39). -EAN/UPC. -EAN128. -Code 128. -Code 93. -CODABAR. -TELEPEN. -PLESSEY. -Code 49. -Code MSI. -Code Delta IBM. -Code 11. -Code 16K. -ISBN/ISSN. -ISBT128. -GS1 DataBar (RSS).
Cable length	2 m
Standard interfaces	RS-232, USB
Input voltage	5 V
Power consumption	180 mA
Power requirements	5VDC ±5%
Housing material	Polycarbonate (PC)
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	160 g
