1 LYNX™
102
4
Windows Controls
Taskbar Enabled
Select/tap “Taskbar Enabled” to specify whether the
taskbar is accessible.
AutoSIP Enabled
Enables the AutoSIP Windows feature.
Scroll Bars Enabled
This control only take effects in WebAppLock.
When checked, displays horizontal and vertical scroll
bars to help view large web pages which do not fit the
screen. W
hen unckecked, those scrolls will not be
present.
Hide Start Button
Select/tap “Hide Start Button” to specify whether the
Start Button is displayed or not. This option works
only when “Task Bar Enabled” is checked.
Windows Wifi Error Dialog
This control only takes effects in WebAppLock and
Internet Explorer.
When checked, the device will display a warning
dialog when the WiFi connected device moves out of
range of an access point and the user attempts to
navigate to a web page. This dialog box allows the
user to reconfigure the wifi on the device.
When unchecked, that dialog box will not appear and
the “Network Disconnected” error page redirection
is
used to prevent users from reconfiguring the wifi on
the device. Tap the “WebAppLock Configuration Tab”
to configure the “Network Disconnected”
error page
redirection (see par 4.12.2).
Changes require a device reboot.
NOTE

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
