Datalogic Lynx User Manual

USE AND FUNCTIONING
47
4
4.5 STATUS INDICATORS
4.5.1 LED Status
The Lynx provides three different LEDs signaling the PDA status.
LED STATUS
Good Read
(right side)
Red
Scanning LED is ON from the time the
user hits the scan button or side trigger
buttons until the bar code is decoded.
Green
Scanning LED is ON, showing a good
decode.
Charging Status
(left side)
Green
It is constant once the charging process
has been completed (full charge).
Red It is constant while charging.
Red blinking
In case of charge fault it is constant for
two hours, then it starts blinking.
Amber
It is constant when charging a severely
discharged main battery until the battery
has sufficient charge for its controller to
begin communicating with the Lynx's
power system. Once the battery is
communicating, the charge LED will
switch to glow red and continue charging
normally.
Keyboard Status
(center)
Off Keyboard in primary.
Yellow solid Yellow alternate key mode.
Blue solid Blue alternate key mode
Sky blue solid CapsLock enabled.

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
