5 TECHNICAL FEATURES
5.1 TECHNICAL DATA
PHYSICAL CHARACTERISTICS
DIMENSIONS (LXWXH)
With Standard Battery: 14.4 x 6.8 x 2.7 cm / 5.6 x
2.6 x 1.0 in
With Hi-
Capacity Battery: 14.4 x 6.8 x 3.3 cm /
5.6 x 2.6 x 1.3 in
WEIGHT
With Standard Battery: 270.0 g / 9.5 oz
With Hi-Capacity Battery: 300.0 g / 10.6 oz
AUDIO
Main (rear) speaker
Receiver (front) speaker
LEDS
Three LEDs Decoding Status/ Keyboard Status/
Charging Status
DISPLAY
TFT-LCD color display QVGA: 320 x 240 pixels;
2.7 in diagonal; 262, 144 color display capability;
Full Graphics with backlight; Touch Screen
KEYBOARD
27-key Numeric or 46-
key QWERTY backlit
keyboard standard;
Side scan keys and volume setting
OPERATING TEMPERATURE* 0º +50ºC (32º to 122ºF)
STORAGE TEMPERATURE -20º +70ºC (-4º to 158ºF)
HUMIDITY** 90% non condensing for temperatures < 40 °C
DROP RESISTANCE***
Withstands drops from 1.2 m (4.0 ft) onto
concrete
ENVIROMENTAL SEALING IP54 standard for water and dust resistance
ESD PROTECTION 4 KV contact discharge, 8 KV air discharge
* In order to achieve the maximum charging rate the LYNX WLAN model should be charged
beetween 0-40 °C, while 3G/4G models should be charged between 0-35 °C.
Never charge the main device or spare batteries in a closed space where excessive heat
can build up. Close to the limits of the working temperature, some display and/or battery
performance degradation may occur. When the battery is discharged, the device with all
phone capability turns off and will not work again until the battery is charged to at least 20%
(or changed out).
Emergency calls are not guaranteed at battery charge status lower than 20%.
** Multiple rapid humidity and/or temperature variations may cause condensing.
*** Multiple drops can permanently damage the device.

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
