Datalogic Lynx User Manual

1 LYNX™
30
3
3.6 WWAN CONNECTION
Lynx 3G/4G HSPA+ models enhance your connectivity solutions giving you an
opening to an international wireless infrastructure that is the global standard.
Lynx uses the following bands:
- UMTS/HSPA+: 800/850/900/1900/2100MHz
- GSM/GPRS/EDGE 850 900 1800 1900 MHz.
In order to use a WWAN Connection you have to install a SIM Card (see instructions
on par. 1.5).
In order to avoid wasting energy, the phone module is off by default.
If you need to have the phone working, the module must be powered
on using the Wireless Manager applet (see par. 4.6.6).
NOTE
Suspending the terminal does not power off the phone radio and the
phone remains connected to the cellular network ready to accept
incoming telephone calls. To prolong autonomy on battery power,
you may turn the phone off when it is not needed using the Wireless
Manager applet.
NOTE
The phone voice capability of this PDA has to be addressed to
occasional use, in well covered areas.
If the coverage is poor, the voice quality can be highly affected.
NOTE

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
