RADIO COMPLIANCE
In radio systems configured with PDAs and access points, the frequencies to be used
must be allowed by the spectrum authorities of the specific country in which the
installation takes place. Be absolutely sure that the system frequencies are correctly
set to be compliant with the spectrum requirements of the country.
The Radio modules used in this product automatically adapt to the frequencies set by
the system and do not require any parameter settings.
The TYPE field shows the correspondence between LYNX™ types and radio
modules:
TYPE: ABCDEE-FGH-IJJK-LMMMM
A: “0” if WWAN module is not present, “E” for GSM/GPRS/EDGE WWAN module, “U”
for HSDPA WWAN module, “H” for HSPA+ Voice and Data
B: “0” if GPS module is not present
C: “0” if IEEE 802.11 module is not present, “A” for IEEE 802.11 abg module, “G” for
IEEE 802.11 bg module, “N” for IEEE 802.11 bgn module
D: “0” if RFID module is not present.
BLUETOOTH® APPROVAL
For more information visit: http://www.bluetooth.org/tpg/listings.cfm.

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
