1 LYNX™
124
5
COMMUNICATIONS
INTERFACES
Micro-USB connector: USB 1.1 Client and USB
1.1 Host
HandyLink™ connector: integrated RS-232 up to
115.2 Kbps, USB 1.1 Client, USB 1.1 Host
Ethernet: via single dock (external modu
le) or
multiple cradle
WIDE AREA NETWORK (WAN)
GSM/GPRS/EDGE: Quad band,
850/900/1800/1900 MHz
UMTS/HSPA+: PH8-P: Five band,
800/850/900/1900/2100 MHz for voice and data
communication; SIM socket under the battery
LOCAL AREA NETWORK (LAN)
Summit IEEE 802
.11 b/g/n Cisco CCX v4
certified
Frequency range: Country dependent, typically
2.4 GHz bands
PERSONAL AREA NETWORK
(PAN)
Bluetooth® Wireless Technology IEEE 802.15
v2.0 with EDR
GLOBAL POSITIONING
SYSTEM (GPS)
Integrated Assisted-GPS (A-GPS)
Hybrid Positioning System

Datalogic Lynx Specifications

General

Display diagonal	2.7 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.806 GHz
Data network	HSPA+
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.0+EDR
Operating frequency	800, 850, 900, 1900, 2100 MHz
Security algorithms	CCX v4
Built-in camera	-
Interface	micro USB, RS-232
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Battery capacity	1800 mAh
RFID reader	No
Product color	Black
Keyboard layout	QWERTY
Keypad number of keys	46
Operating system installed	Windows Embedded Handheld 6.5

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	144 mm
Weight	270 g
