Interleaved 2 of 5 (I 2 OF 5) Enable
Product Reference Guide 5-233
I 2 of 5 Fixed Length 2
This feature specifies I 2 of 5 second fixed length.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET I 2 OF 5 FIXED LENGTH 2 below. You’ll
need to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired fixed label length. The selectable range for this
option is 00, or 02 to 50; even numbers only. Pad all single digit
numbers with a leading zero to yield a two-digit entry (02-50).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET I 2 OF 5 FIXED LENGTH 2
NOTE
This applies when I 2 of 5 Length Control is set to fixed-length
decoding.
If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will
apply.
