Datalogic Magellan 2200VS Product Reference Guide

E-14 Magellan
TM
2200VS and 2300HS
I 2 of 5 Check
Character
Transmission
1
(enable
)
1
(enable)
1
(enable)
1
(enable
)
1
(enable)
1
(enable)
1
(enable)
1
(enable)
I 2 of 5 AIM ID
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
I 2 of 5 Label
ID
6900
("i")
6900
("i")
4900
("I")
4232
("B2")
6900
("i")
6900
("i")
I 2 of 5 Length
Control
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
0
(vari-
able)
I 2 of 5 Maxi-
mum Label
Length
50 50 50 50 50 50 50 50
I 2 of 5 Mini-
mum Label
Length
66666666
I 2 of 5 Fixed
Length 1
10 10 10 10 10 10 10 10
I 2 of 5 Fixed
Length 2
00000000
I 2 of 5 Stitch-
ing
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Codabar
Enable
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Codabar Start
Stop Charac-
ter Transmis-
sion
0 (dis-
able)
0 (dis-
able)
1
(enable)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
0 (dis-
able)
Codabar Start
Stop Charac-
ter Set
3
(abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
3
(abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
Table E-2
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17
OEM
USB
USB
Keybd
PC
KBW

Datalogic Magellan 2200VS Specifications

General

Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional.
Standard interfaces	USB, RS-232
Dimensions (WxDxH)	152 x 152 x 97 mm
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
