Installation
QUICK REFERENCE GUIDE 3
Figure 3. USB + Power Cable Power Off the Terminal
Figure 4. Powered by AC Adapter
Terminal (PC)
RJ Host Port
Connector
Power
USB + Power Cable
Power Off the Terminal (POT)
U
S
B
R
S
-
2
3
2
RS-232 and USB Cables
Powered by AC Adapter
To Terminal (PC)
