Datalogic Matrix 300

MATRIX 300™ QUICK GUIDE
23
Data Matrix Code 0.19 mm (7.5 mils)
Measurement Conditions:
Tilt Angle: 45°
Skew Angle: 15°
See the Matrix 300™ Reference
Manual for a complete list of
conditions.
For applications where DOF is
important, pre-configured .ini files are
provided which correspond to these
reading diagrams. See the Matrix
300™ Reference Manual for details.
Reading Distance
Horizontal Reading Width
m
m
in
0 1 2 3 4 5 6
0
1
2
3
-1
-2
-3
