MATRIX 300™ QUICK GUIDE
25
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
4x2-01x models
4x2-04x models
Supply Voltage
10 to 30 Vdc
PoE Device 48 Vdc
Consumption
0.7 to 0.2 A max
13 W max.
Communication Interfaces
Main
- RS232
- RS485/422 full-duplex
2400 to 115200 bit/s
2400 to 115200 bit/s
Auxiliary - RS232
2400 to 115200 bit/s
ID-NET™
Up to 1MBaud
Ethernet
10/100 Mbit/s
Inputs: Input 1(External Trigger)
and Input 2
Opto-coupled and polarity insensitive; (see Reference Manual for details)
Outputs: Output 1, 2 and 3
NPN or PNP short circuit protected; (see Reference Manual for details)
OPTICAL FEATURES
Image Sensor
CMOS sensor with Global Shutter
Image Format
SXGA (1280x1024) pixels
Frame Rate
60 frames/sec
Pitch
35°
Tilt
0° - 360°
Lens
Focal Length = 9 mm; Focus Control via software
Lighting System
Internal Illuminator
Aiming System
Laser Pointers
LED Safety/Laser Safety (pointers)
to EN 62471 / IEC 60825-1 2007
PHYSICAL FEATURES
Connector position 0°
Connector position 90°
Dimensions
95 x 54 x 43 mm (3.7 x 2.1 x 1.7 in.)
75 x 54 x 62 mm (3.0 x 2.1 x 2.4 in.)
Weight
about 238 g. (8.4 oz.)
Material
Aluminium
