ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES
226
POWERSCAN™ PD/PM/PBT9600
Data Matrix Set Length 2
This feature specifies one of the bar code lengths for "Data Matrix Length Control" on
page 225
. Length 2 is the maximum label length if in Variable Length Mode, or the sec-
ond fixed length if in Fixed Length Mode. Characters can be set from 0001 to 3,116 char-
acters in increments of 0001 (pad with zeroes).
See "
Set Length 2" on page 342 for detailed instructions on setting this feature.
Select Data Matrix Length 2 Setting
$CDML2
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar
code at left followed by the digits from the Alphanu-
meric characters in Appendix G, Keypad represent-
ing your desired character(s). End by scanning the
ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
Length 2 is 3,116 Characters
