POWERSCAN™ PD/PM/PBT9600
APPENDIX A
TECHNICAL SPECIFICATIONS
The table below contains Physical and Performance Characteristics, User Environment
and Regulatory information. Table 37 provides Standard Cable Pinouts.
PD9600 TECHNICAL SPECIFICATIONS
Table 30 PD9600 Technical Specifications
PHYSICAL CHARACTERISTICS
Color
Yellow/Black
Dimensions
Height 19.0 cm (7.5'')
Length 14.0 cm (5.5”)
Width 7.9 cm (3.1”)
Weight (without cable)
305 gr. (10.7 oz.)
ELECTRICAL CHARACTERISTICS
Input Voltage
5 - 30 VDC ± 5%
Current
Consumption
Operating (Typical):
PD9630-SR: 200mA @ 5V; 120mA @ 12V
PD9630-HP/ PD9630-DC:
280mA @ 5V / 140mA @ 12V
Standby/Idle (Typical):
187mA @ 5V / 92mA @ 12V
Reading Indicators
Top illumination, Good Read Spot, Beep, Vibration
Interfaces Supported
USB, RS-232, Ethernet
OPTICAL CHARACTERISTICS
Optical Format
1/4"
Imager Sensor
1280 H x 800 V
Illumination System
White LED
Aiming System
630 - 680 nm VLD
Reading Angle
All models:Pitch: +/- 52°; Skew: +/- 52°
Field of View
HP: 38° x 24°
STD: 38° x 24°
DC: 51° x 33.5
Print Contrast Ratio
minimum 15%
