ACTION CONFIGURATION FOR FUNCTION KEYS
Configure actions for the function keys.
Table 6 - Default Action Keys
To configure the following features, follow the procedure below:
1. Scan the ENTER/EXIT PROGRAMMING MODE bar code above.
2. Scan the bar code for the Function Key you want to program.
3. Determine the CMD_ID number from Table 5 on page 256.
4. Scan the corresponding 2 digits from the Alphanumeric characters in
Appendix G,
Keypad
.
5. End the procedure by scanning the ENTER/EXIT bar code again.
16K 4K
F1
07 Backlight 02 String 1
F2
0E Dot char 03 String 2
F3
09 Backspace CMD N.A.
F4
08 Clear N.A.
Shift
10 Shift N.A.
$CKF11
Configures Action for F1
Configures Action for F2
$CKF21
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
To Next Page
