Datalogic QuickScan QBT2400 Quick Reference Guide

Linking the Reader
12 QuickScan™ QBT2400
Linking to a Bluetooth Adapter in HID mode
1. Install any drivers provided with the Bluetooth
adapter.
2. Scan the
Link to PC in HID label below..
3. Use the host computer’s Bluetooth manager to
“Discover new devices” and select "Datalogic
Scanner." If you receive an error message, it may
be necessary to disable security on the device.
4. Use a text editor to see incoming data on the
port designated by the computer's Bluetooth
manager..
NOTE
The QBT2400 reader can be set up to require a
PIN code when connecting. If you want to set
up a PIN, or when adding new equipment to a
system that uses a custom security PIN, please
see the PRG for information.
Link to PC in HID

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
