Datalogic QuickScan QBT2400 Quick Reference Guide

Hex-Numeric Keypad
Quick Reference Guide 45
Hex-Numeric Keypad (continued)
C
D
E
F
For HID Variable Pin Code only
If you make a mistake, scan the CANCEL barcode below
to abort and not save the entry string. You can then
restart.
Finish by scanning the Exit HID Variable PIN Code label.
Cancel an incomplete HID Variable PIN Code
Exit HID Variable PIN Code

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
