Datalogic QuickScan QBT2400 Quick Reference Guide

Programming
Quick Reference Guide 15
HID Alt Mode
Read the configuration command label below for the HID
Alt Mode feature.
Power Off
Scan the bar code below to shut off power to the handheld
until the next trigger pull.
PowerOff
ENTER/EXIT PROGRAMMING MODE
♦ HID Alt Mode = OFF
HID Alt Mode = ON

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
