Datalogic QuickScan QBT2400 Quick Reference Guide

Quick Reference Guide i
Table of Contents
END USER SOFTWARE LICENSE AGREEMENT (EULA) ............ iii
Software Product Policy ............................................................. vi
Description .................................................................................... 1
Setting Up the Reader ................................................................. 2
Locking the Reader to the Base ........................................ 2
To Lock the Reader in the Base................................ 2
Connecting the Base Station ...................................................... 4
Base Station Connection and Routing .............................. 4
System and Network Layout ............................................. 6
Typical Setup with Cradle and Host ......................... 6
Using the BC2030™ Radio Base ......................................... 6
Radio Base LEDs ........................................................ 6
Charging the Batteries ....................................................... 8
Replacing the Battery Pack ................................................ 9
Using the Quickscan™ QBT2400 ...............................................10
Linking the Reader .....................................................................11
Link Datalogic RF Devices to Base......................... 11
Linking to a Bluetooth Adapter in Serial Port Profile
Mode.......................................................................... 11
Linking to a Bluetooth Adapter in HID mode........ 12
Variable PIN Code .................................................... 13
Programming ..............................................................................14
Using Programming Bar Codes .......................................14
Configure Other Settings ..................................................14
Resetting Standard Product Defaults ............................ 14
HID Alt Mode ......................................................................15
Power Off ........................................................................... 15
Country Mode .............................................................................16
Caps Lock State .......................................................................... 20
Selecting the Base Interface Type ............................................ 21
Interface Selection ............................................................ 21
Configuring the Interface ........................................ 21
Keyboard Interface .................................................. 23
Scancode Tables....................................................... 25
Numlock.................................................................... 26
Reading Parameters .................................................................. 26
Aiming System ..................................................................26
Good Read Green Spot Duration .....................................27
Scan Modes ................................................................................28
Pick Mode ...........................................................................30
Multiple Labels in a Volume ............................................30
Technical Specifications ............................................................ 31

Datalogic QuickScan QBT2400 Specifications

General

Connectivity	Bluetooth
Battery Type	Lithium-Ion
Battery Capacity	1400 mAh
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Interfaces Supported	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Radio Range (Open Air)	100 m
Type	Handheld
Scan Rate	60 frames per second
Resolution	0.1 mm
Humidity	5 to 95% non-condensing
Light Source	Red LED
Supported Barcodes	1D / 2D and postal codes
