LED and Beeper Indications
36 QuickScan™ QBT2400
a Except when in sleep mode or when a Good Read LED Duration other than
00 is selected
Programming Mode
- The following indications ONLY occur when
the reader is in Programming Mode.
Green Spot
a
flashes
momentarily
Upon successful
read of a label, the
software shall turn
the green spot on
for the time speci-
fied by the config-
ured value.
N/A N/A
Indication Description LED Beeper
Label Program-
ming Mode Entry
A valid program-
ming label has been
scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.
Label Program-
ming Mode Accep-
tance of Partial
Label
In cases where
multiple labels
must be scanned to
program one fea-
ture, this indication
acknowledges each
portion as it is suc-
cessfully scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and cur-
rent volume.
Label Program-
ming Mode Accep-
tance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Program-
ming Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Program-
ming Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
Indication Description LED Beeper
